Geometry
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Wheel Size | 700 | 700 | 700 | 700 | 700 | 700 |
| Stack | 485mm | 506mm | 522mm | 540mm | 559mm | 587mm |
| Reach | 381mm | 398mm | 412mm | 425mm | 437mm | 443mm |
| Head Angle | 71° | 72.5° | 72.5° | 72.5° | 72.5° | 72.5° |
| Seat Angle | 75-79° | 75-79° | 75-79° | 75-79° | 75-79° | 75-79° |
| Top Tube Length | 511-475mm | 533-496mm | 551-513mm | 570-530mm | 587-546mm | 600-567mm |
| Head Tube Length | 87mm | 101mm | 118mm | 137mm | 157mm | 187mm |
| Standover | 732mm | 785mm | 773mm | 790mm | 808mm | 836mm |
| Fork Trail | 62.4mm | 62.4mm | 62.4mm | 62.4mm | 62.4mm | 62.4mm |
| Fork Offset | 54mm | 43mm | 43mm | 43mm | 43mm | 43mm |
| Bottom Bracket Drop | 75mmmm | 75mmmm | 75mmmm | 75mmmm | 75mmmm | 75mmmm |
| Front Center | 582mm | 583mm | 602mm | 622mm | 640mm | 654mm |
| Wheelbase | 975mm | 976mm | 995mm | 1015mm | 1033mm | 1047mm |
| Chainstay Length | 405mm | 405mm | 405mm | 405mm | 405mm | 405mm |
