Road Complete Bicycles
Description

Limited quantities of these world-class AC-R framesets adorned with an 11 speed Shimano Ultegra 6800 drivetrain, Shimano wheelset and quality Deda bar and stem, Selle Italia saddle and Vittoria rubber. It's add water and mix with no upgrades necessary with this one.

We are pleased to offer rare special pricing and availability on this Colnago AC-R complete bike. The overall value is astonishing, and the mixed Ultegra 6800 11 speed AC-R is an even stronger value than it's 105 equipped sibling. In upgrading to Ultegra STI levers,with both front and rear derailleurs, the price option difference will truly come down to where your final budget sits. You can't go wrong with the AC-R 105, but if you can get the lighter weight, performance and advanced materials used in Ultegra, especially in the high-use shifters and rear derailleur, you have to look more closely at the budget! It is rare to find such a quality build and frameset from Colnago available as a complete bike at these prices.

The frameset features a tapered head tube and fork steerer for extra front end stiffness and stability, which help the AC-R tackle tricky descents and tight corners with confidence. The tapered 1⅛" - 1¼" full carbon fork complements the frame with light weight, stiffness and confidence inducing control of the front half of the bike. In the main triangle, tube shapes are defined by strength and torsional requirements, with vertical compliance factored in. A standard BSC (English) threaded bottom bracket is simple and reliable, minimizing troublesome bearing issues and keeping the cost of the frame manageable. The wishbone-style rear seat stay delivers a smooth ride, but when paired with the shaped chainstays transfers pedaling power to the rear wheel. Colnago has gone to great efforts to build the AC-R to be race worthy, yet in an eminently rideable design, meeting the UCI standards for racing frames by undergoing all the extensive safety testing required by the UCI pro level racing, just like the twelve thousand dollar bikes used by the top riders.

Colnago has more experience than any other brand from six decades of tweaking bicycle fit and geometries in conjunction with countless pro teams and riders. The riding position of the AC-R is the appropriate mixture of performance and comfort. Both the exercise enthusiast and those dabbling in racing will appreciate the solid sense of nimble control that only a Colnago can offer. The balance, handling, and positive road feel all lead to excitement whether you are tackling your local crit, gran fondo, or Sunday morning ride with friends.

Frameset Details

  • Full carbon monocoque AC-R frame engineered from Japanese Toray carbon fiber
  • Toray HM (High Modulus) tapered carbon fork (1⅛ to 1¼)
  • Rear wishbone design mono-stay for comfort, lateral stiffness
  • Reliable 68mm threaded BSC (English thread) bottom bracket
  • Internal derailleur cable routing
  • Proven Colnago AC-R/M10 sloping geometry

Drivetrain and Cockpit

  • Shimano Ultegra 6800 STI brake/shift levers
  • Shimano Ultegra 6800 front derailleur
  • Shimano Ultegra 6800 rear derailleur
  • Shimano 105 5800 11-28t cassette
  • Shimano FC-RS500 50x34 crankset
  • Shimano Ultegra 6800 Hollowtech II BSC bottom bracket
  • KMC X11 Silver chain
  • Colnago/TRP X3 alloy dual pivot brakeset
  • Shimano RS10 wheelset
  • Deda Zero 1 stem
  • Deda Zero RMH handlebar
  • Deda handlebar tape
  • Colnago/Deda 31.6mm alloy seatpost
  • Colnago/Selle Italia X01 Vanadium saddle
  • Vittoria Zaffiro 700x23c folding tires

Sizing your AC-R: Colnago describes the frame size as the actual seat tube length from the center of the bottom bracket to about the middle of the seat collar extension.

One easy way of determining your size is to measure your existing frame's effective toptube (measure the horizontal distance from center of headtube to center of seatube) and compare with the AC-R toptube. The other way is to simply size down one size from your regular size to get your Colnago AC-R size. For example, if you're a 54cm in your current frame then downsize to a 52s.

Return to Top
Geometry
Size 54 56 58 48cm 51 61
Wheel Size 700 700 700 700 700 700
Stack 540mm 565mm 590mm 491mm 515mm 615mm
Reach 383mm 392mm 401mm 365mm 374mm 410mm
Head Angle 73° 73° 73° 71° 72° 73°
Seat Angle 73° 73° 73° 73° 73° 73°
Top Tube Length 130mm 156mm 184mm 516mm 532mm 598mm
Head Tube Length 548mm 565mm 581mm 86mm 106mm 211mm
Standover 774mm 798mm 824mm 708mm 47.8mm 848mm
Fork Offset 44.5mm 45.5mm 45.5mm 57.5mm 51.5mm 45.5mm
Bottom Bracket Drop 72mm 72mm 69.5mm 74.5mm 74.5mm 69.5mm
Front Center 578mm 595mm 611mm 574mm 576mm 628mm
Wheelbase 977mm 994mm 1011mm 972mm 974mm 1028mm
Chainstay Length 410mm 410mm 410mm 410mm 410mm 410mm
