Cervelo Aspero Force eTap AXS 1 Bicycle 2021
SRAM's Force eTap AXS 1x12 drivetrain is a perfect match for the Cervelo Aspero gravel race frame design. Speed, agility, compliance, and handling performance that allows the rider to attack and endure all day long are what makes this capable, fun bike more like a road bike than any gravel option we have seen to date. The Aspero Force eTap AXS 1 will surely deliver for those who love to go out and rip it up. This is a gravel bike for hard single day efforts in training or racing modes, or 2-3 hour rides with friends on country roads and hardpack trails. Cervelo has designed a frameset with somewhat unique features and properties that deliver a gravel riding experience road cyclists will embrace.
Inspiration from the Aspero frame construction and features has come from several Cervelo models, yet the design has been engineered from the frame up for the race gravel concept for which it was conceived. You will see the R3's Squoval.Max tubeset shapes in the Aspero, along with details from the C, S, and P series models. Aero inspiration has always a driving force for Cervelo, and the toptube shares the shape and a hidden 2-bolt SmartPak bag mount of the P5 that is compatible with several aero and storage bags available today. The internal reference design points exemplify elements of Cervelo's best engineering to date, and all serve the gravel race concept: fit, speed, balance, handling, and set-up flexibility.
That said, it is the engineering behind the frame geometry, fork design, an adjustable trail set-up, and overall frame stability that define the Aspero. One major goal was to provide the clearance necessary for 650b x 51mm tires, or 700c x 43mm tires with at least 4mm on either side to spare. This was accomplished in a few key ways. Up front the fork legs have a new carbon lay-up and shaping from the large 12mm thru-axle dropout on up, with an integrated crown that isn't as vertically thick as you'd expect, yet still inherently strong and gravel ready with great rounded tire clearance. Cervelo also was able to maintain a standard front-center measurement, by elongating the top tube, maintaining a road-style seattube angle, and proper trail via an adjustable front dropout design. More on that below. The center of gravity is moved rearwards, as the headtube angles are more gravel/cyclocross than road. The 56cm toptube of the Aspero is 9mm longer than the 56cm R3. The headtube itself was kept essentially at R3 road lengths per size, which along with the impressive fork design and integrated headset means that the forward cockpit position feels more like a road bike- your saddle drop to bar can be more like your road fit. At the rear triangle a 420mm chainstay length was achieved with the familiar dropped chainstay design, and a seat-tube cut-out for stability and power response.
The engineers focused on the Aspero handling properly regardless of wheel and tire size, without compromising the headtube angle. The concept of fork "Trail" is best known in the mountain bike world, but is relevant across all cycling. Cervelo's Trail Mixer system allows the rider to keep effective Trail at 62mm. Larger variations in tire size effect the rearward position of the tire- affecting handling and toe-overlap clearance. By using off center, bolt-in 12mm thru-axle drop outs, the rider can select the +5 forward position or the -5 rear position of the axle. With a 700x42 gravel tire set-up, similar to the stock Aspero Force eTap AXS 1 bike, the +5mm forward is the proper position for best active handling and nimble bike control, which is what faster, race-oriented users want on more technical surfaces. If you moved it to the -5mm rearward position, it would slow the handling down, perhaps better for long, flat rides on firmer, smoother, less technical surfaces. The principles of Trail set-up come down to the outside diameter of a mounted tire and desired handling characteristics to determine your Trail Mixer set-up. This is true for 650b use, or running a lower volume 700c tire. Cervelo has a more complete explanation of the mechanically simple Trail Mixer system on their website.
The use of the modified Squoval.Max tubeset is clear with the Aspero featuring a substantially larger downtube and massive bottom bracket junction over the R3. The integrated fork crown and downtube design resembles the Dropped Downtube of the aero bikes but it seems more functional for strength and visual balance from the tapered headtube through the downtube. The seattube features a squared back, cut-out design, but carries a 27.2mm round seatpost, which can provide more vertical compliance and offers more options. Everything, from the dropped, oversized chainstays, slightly curved, shaped aero seatstays, rear dropouts and Flat Mount disc interface are all stouter for increased strength. A modified Future Proof cable guide/internal routing system has an option for a cabled or hydraulic dropper seatpost, and a bolt-on downtube protector handles the debris coming off the front wheel.
The build kit steps up with the 2021 Aspero Force eTap AXS 1. Of course it centered around the wireless AXS 1, 1x12 groupset, which is durable, precise, and offers a super clean build. Easton's carbon bar and seatpost add vibration damping and comfort, while the lightweight alloy stem delivers stiffness and control. 32mm Reserve carbon rims are laced to DT370 Center Lock disc hubs, and carry the fast but traction finding 38mm Panaracer Gravel King SK tires. This Aspero is built and equipped for speed and joy. Are you?
- Wonderfully capable carbon gravel race bike featuring SRAM Force eTap AXS 1 HRD
- Lower, more stable road-like feel from overall geometry, chainstay length, BB drop
- Longer toptube moves COG back; low forward position; 62mm optimal Trail
- Accepts 700c x 43mm tires / 650b x 51mm tires; minimum 4mm side clearance
- Trail Mixer fork dropouts can be switched for +/- 5mm selectable fork offset
- Basic Rule (For 700c): Small(OD)= -5, Big(OD)= +5
- Forward position=decreased trail=faster handling
- Rearward position=increased trail=slower handling
- Trail Mixer design maintains BB drop, effective headtube angle in any setting
- Various Cervelo tube designs from R-Series utilized; enhanced for strength/terrain
- Full carbon tapered fork designed for Aspero, with thru-axle, Flat Mount disc
- Fork features aero integration to downtube with larger, stouter crown design
- Large downtube BBright shell transitions deftly into oversized dropped chainstays
- Carbon lay-up, round seatpost, larger volume tires contribute to rider comfort
- Internal routing, downtube hose guide; option for cabled/hydraulic dropper post
- 1x/2x compatible, with mechanical or electronic shifting systems
- Bolt-on downtube frame protector, two bolt toptube bag mount w/cover
- Threaded thru-axles: 12/100mm fork, 12/142mm rear
- Front derailleur mount removed for 1x chainring set-up
- Force eTap AXS HRD 1x12; DUB crank/BB w/36T X-Sync ring, XG1270 10-36 XDR cassette
- Flat Mount HRD disc calipers with Paceline 160mm rotors
- Reserve 32mm Carbon rim on DT370 Hubset (XDR), 24h (F/R), 24mm Internal rim width, Center Lock disc, TLR
- Panaracer Gravel King SK Folding 700x38 tires
- Easton cockpit: Easton EC70 AX Carbon bar, EA90 stem, EC70 carbon 27.2 seatpost
- Prologo Dimension NDR T4.0 saddle
- Includes eTap battery, USB cord, charging dock, Smartpak 400A Toptube bag
- Color: Carbon/Red, Black/Gold
- Sizes: 48, 51, 54, 56, 58 cm (48, 51, 54 have Zero offset seatpost)
- Weight: 17.61 lbs (54cm)
|Top Tube Length||512mm||532mm||553mm||575mm||591mm||608mm|
|Head Tube Length||83mm||107mm||133mm||159mm||188mm||314mm|
|Bottom Bracket Drop||78.5mm||78.5mm||76mm||76mm||73.5mm||73.5mm|
