Bicycles > Road > Complete
Description
Endurance road bikes walk a line between comfort and performance, and the Cervelo Caledonia-5 Ultegra R8170 Di2 plants its flag firmly on the performance side while still delivering the compliance needed for triple-digit mileage days. The carbon frame uses dropped seatstays borrowed from Cervelo's Aspero gravel platform, creating an acute rear triangle that flexes vertically to absorb road chatter without sacrificing the lateral stiffness that makes the bike accelerate when you stand on the pedals. Slimmer tube profiles throughout the frame reduce weight while maintaining the structural integrity Cervelo engineered into the original Caledonia-5 design.
The newest generation adds integrated downtube storage that holds a tube, multi-tool, and CO2 canister beneath the bottle cage. The hatch opens easily with gloves on, putting your flat kit within reach without the saddle bag that disrupts the bike's clean lines. This is a detail borrowed from Cervelo's P-Series triathlon bikes, where every aerodynamic advantage matters. The Caledonia-5 applies that same thinking to road riding, hiding all brake and shift control lines inside the frame and fork to reduce drag. The bike may be built for comfort over long distances, but it still slices through the wind like the race machine its engineering suggests.
Fit adjustability sets this bike apart from competitors with fixed integrated cockpits. The split bearing caps allow you to swap between high and low positions without bleeding the brakes, and the stack range spans from an aggressive 7mm to a relaxed 22mm without spacers. Riders who want their bars slammed get a clean look; riders who need a more upright position get the same integration. The geometry maintains consistent 415mm chainstays across all frame sizes, keeping handling predictable whether you're on a 48cm or 61cm frame.... Read More
Features
- Caledonia-5 carbon frame with dropped seatstays for vertical compliance
- Shimano Ultegra R8170 Di2 12-speed semi-wireless electronic drivetrain
- 4iiii Precision Pro GEN3+ dual-sided power meter
- 52/36T chainrings with 11-34T cassette
- Reserve 42|49TA carbon wheelset with Zipp hubs
- Vittoria Corsa N.EXT TLR G2.0 700x30c tubeless-ready tires
- Shimano Ultegra hydraulic disc brakes with 160mm Center Lock rotors
- Cervelo HB13 carbon handlebar with ST32 alloy stem
- Cervelo SP24 carbon D-shape seatpost
- Selle Italia Novus Boost Evo SuperFlow Ti saddle
- Integrated downtube storage for tube, tool, and CO2
- Split bearing caps for stack adjustment without brake bleeding
- 36mm maximum tire clearance with removable fender mounts
- Fully internal cable and hose routing
- UCI approved with lifetime warranty
- 17.53 lbs (size 56)
Geometry
| Size | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Wheel Size | 700 | 700 | 700 | 700 | 700 | 700 |
| Stack | 505mm | 530mm | 555mm | 580mm | 605mm | 630mm |
| Reach | 360mm | 369mm | 378mm | 387mm | 396mm | 405mm |
| Head Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| Seat Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Top Tube Length | 502mm | 522mm | 543mm | 565mm | 581mm | 598mm |
| Head Tube Length | 89.5mm | 110.3mm | 136.3mm | 162.2mm | 191.5mm | 217.8mm |
| Standover | 701mm | 743mm | 775mm | 798mm | 824mm | 847mm |
| Fork Trail | 57.8mm | 57.8mm | 57.8mm | 57.8mm | 57.8mm | 57.8mm |
| Fork Offset | 60mm | 54mm | 51mm | 51mm | 51mm | 51mm |
| Bottom Bracket Drop | 76.5mm | 76.5mm | 74mm | 74mm | 71.5mm | 71.5mm |
| Front Center | 580.5mm | 582.7mm | 592.5mm | 609.5mm | 627mm | 644.1mm |
| Wheelbase | 983.3mm | 958.6mm | 996.3mm | 1013.4mm | 1031.8mm | 1048.9mm |
| Chainstay Length | 415mm | 415mm | 415mm | 415mm | 415mm | 415mm |
