Description
The Cervelo ZFS-5 was designed to be a high-performance cross-country mountain bike which features a single pivot, flex stay suspension system. This design efficiently converts the rider's pedaling energy into forward motion, resulting in excellent speed and efficiency. The bike is equipped with 29-inch wheels, which not only maintain speed effectively but also minimize the impact of obstacles and rough terrain.
The rear suspension of the ZFS-5 offers 115mm of travel, enabling it to handle drops, small jumps, and various challenges found on modern trails. Additionally, this version of the bike is equipped with a 120mm fork, enhancing its capabilities further. The inclusion of this fork results in a slack head tube angle of 66.6 degrees, enhancing stability and composure when descending steep trails. For uphill climbing, the ZFS-5 features an efficient 75-degree seat tube angle, ensuring powerful and effective pedaling. Moreover, the bike's medium-length, size-specific chainstays contribute to a nimble, stable, and well-balanced riding experience across all frame sizes.
The Cervelo ZFS-5 120 is equipped with SRAM's X0 Eagle wireless Transmission AXS build which incorporates state-of-the-art advancements in the electronic drivetrain realm. The SRAM X0 Eagle Transmission AXS drivetrain ensures flawless and precise gear shifting, accompanied by an extensive gear range, all while eliminating the need for traditional cables. The drivetrain components are engineered for exceptional durability, catering to high-performance demands. Braking efficiency is fortified by the SRAM Level Silver Stealth brakes, employing a 4-piston setup to provide substantial stopping power when required. Additionally, the Maxxis Rekon tires deliver optimal traction and grip, minimizing rolling resistance for enhanced performance.... Read More
Features
- SRAM X0 Eagle, 32T, Boost 148 DUB
- SRAM DUB, BSA 73mm Bottom Bracket
- SRAM X0, 12 speed Chain
- SRAM X0 Eagle AXS, 12 speed Rear Derailleur
- SRAM X0 Eagle, 10-52, 12 speed
- SRAM AXS Rocker Shifter
- Race Face Next R Carbon, 35mm clamp, 780mm width, 20mm Rise Handlebar
- Race Face Aeffect R Alloy, 35mm clamp, 0 degree Stem
- SRAM Level Silver 4 Piston Brake Levers and Calipers
- Prologo Dimension NDR T4.0 Saddle
- SRAM Reverb AXS 30.9 Wireless Dropper Post
- SRAM Centerline Center Lock Rotors
- Fox Performance Elite 34 Step-cast, FLOAT EVOL air spring, Fit 4 3-position crown-adjusted damper, tapered steerer, 15x110mm, Kabolt axle, 44mm offset, 120mm travel
- Rockshox SIDLuxe Select+, RL 3 position damper, 190 x 45mm
- FSA IS2 1-1/2 x 1-1/2 Headset
- Front Wheel: Reserve 28 XC, 28mm IW, DT Swiss 350, 15x110mm, 24H, Center Lock, tubeless compatible
- Rear Wheel: Reserve 28 XC, 28mm IW, DT Swiss 350,12x148mm, XD freehub, 24H, Center Lock, tubeless compatible
- Maxxis Rekon, EXO 60 TPI, 29x2.4
- Weight: 25.98lbs (Size Medium)
Geometry
| Size | Small | Medium | Large | Xtra Large |
|---|---|---|---|---|
| Wheel Size | 29" | 29" | 29" | 29" |
| Stack | 584mm | 590mm | 601mm | 601mm |
| Reach | 421mm | 445mm | 469mm | 496mm |
| Head Angle | 67.8° | 67.8° | 67.8° | 67.8° |
| Seat Angle | 76.5° | 76.3° | 76.2° | 76° |
| Top Tube Length | 561mm | 589.1mm | 617.3mm | 649.1mm |
| Head Tube Length | 96mm | 102mm | 114mm | 128mm |
| Standover | 746mm | 744mm | 744mm | 744mm |
| Fork Offset | 44mm | 44mm | 44mm | 44mm |
| Bottom Bracket Drop | 42mm | 42mm | 42mm | 42mm |
| Front Center | 692mm | 718mm | 746mm | 779mm |
| Wheelbase | 1120mm | 1149mm | 1180mm | 1215mm |
| Chainstay Length | 432mm | 435mm | 437mm | 440mm |
